AutoBale 600
PRODUCT OVERVIEW
Product Code: MP-HX600AB
The AutoBale 600 is a high‑capacity, conveyor‑fed semi‑automatic horizontal baler engineered for continuous industrial processing of cardboard, paper, and mixed packaging waste. Material is delivered via an integrated conveyor into a reinforced horizontal compression chamber, where a high‑force hydraulic ram forms dense, export‑grade mill‑size bales with consistent cycle performance. Built for 24/7 operation, the system delivers high throughput, uniform bale quality, and reliable side‑eject discharge. Its precision‑machined hydraulics, automated cycle control, and intuitive operator interface make it ideal for recycling plants, logistics hubs, and high‑volume production facilities demanding durability, efficiency, and continuous workflow.
Description
MACHINE DIMENSIONS & WEIGHT
Overall Length: 12–20 ft (3.6–6 m) including conveyor
Overall Width: 5–8 ft (1.5–2.4 m)
Overall Height: 7–10 ft (2.1–3 m)
Machine Weight: 5–7 tons
Feed Opening: Large‑format horizontal aperture
SUITABLE APPLICATIONS:
Paper
Card
Plastic
Cloth
Polystyrene
Metal Containers
Light Rubber & Synthetic Materials
Foam Materials
Agricultural & Organic Packaging Waste
Manufacturer: MegaPress Machinery Limited
Additional information
| Product Name | AutoBale 600 |
|---|---|
| Product Code | MP-HX600AB |
| Compaction Force | 40–80 tons, |
| Bale Weight | 300–600 kg, |
| Throughput | 2–6 tons/hr, |
| Cycle Time | 35–45 sec, |
| Product Type | Conveyor‑Fed Semi‑Automatic Horizontal Baler, |
| Construction Material | Heavy‑gauge welded steel frame, |
| Occupancy Rating | 3 persons, |
| Electrical System | 3-phase (460–480V, |
| Feed System | Conveyor‑fed, |
| Ejection | Side‑eject semi‑automatic, |
